parking lot detection and guidance system

FOB Reference Price:Get Latest Price
US $1-500 / Pieces | 1 Piece/Pieces (Min. Order)
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Fujian, China (Mainland)
Brand Name:
Keytop
Work temperature::
-20--+60℃
Rate Voltage::
AC110--220V
Power:
1.5w
Size:
300*260*73mm
Supply Ability
Supply Ability:
100000 Piece/Pieces per Month
Packaging & Delivery
Port
Xiamen, China





Product Description



1 Zone Control Unit of parking guidance :

1) The LCD in ZCU is to show the detector's working status.

2) Main Functions:

It is to inquire about the relevant sensor status via RS485-B by turns and forward the data by RS-485-C. Meanwhile, ZCU forwards the commands of CCU to LED SCREEN via RS-485-B.







2.How parking guidance system (car park system) Works:



Firstly, UD takes use of ultrasonic wave to detect the car space to see if it is occupied by vehicles and transfer relative command to LED Indicator which will turn from green to RED when occupied, or it will keep GREEN;

meanwhile, the UD transmit its status message to ZCU immediately, and ZCU will collect and forward the information to CCU; CCU processes these data and sends the relevant command to ZCU and LED panel.



System Layout

 paste-pic-dp_uuid_ze56t



Packaging& Delivery










Global Cases





         Poland Krakow Airport(1160 lots)




        Philipine Mall of Asia(3160 lots)


Singapore  Changi Airport(3850 lots)








Certifications



UD CE.JPG
